Custom Dehumidifiers

Condensation Dehumidifier (Custom)

The condensation dehumidifier achieves very low humidity levels, with the dehumidifier optimized to minimize energy consumption. The dehumidifier is particularly energetically efficient in very hot and humid air that condenses easily.


Process air 0 – ∞
Dehumidification capacity As requested
Connection voltage 400 / 50 / 3 V / Hz / Ph+N+PE

The cabinet consists of a robust steel frame with aluminum cabinet profiles. Where the double-walled and insulated panels are made of galvanized and powder-coated sheets. Guaranteed a product of excellent quality.

Download brochure

Features

  • Guaranteed product quality
  • High reliability
  • Achieves low humidity levels
  • All components are accessible through the housing
  • Optimized to minimize energy consumption
  • Particularly energetically efficient with very hot and humid air that condenses easily

High-quality materials

  • Robust steel frame
  • Aluminium cabinet profiles
  • Double-walled and insulated panels made of galvanized and powder-coated plate
  • Cabinet panels are smooth on the inside for hygiene reasons

Specs

  • PLC control including stepless capacity control cooling system 40-100%
  • Touchscreen for process visualisation, parameter setting and status display
  • Integrated control cabinet with electrical components
  • Temperature sensors
  • Industrial T+RV sensor outside air
  • Semi-hermetic suction gas-cooled R513a compressor, frequency controlled
  • High- and low-pressure safety devices according to PED
  • Industrial high-pressure liquid tank
  • Cross-flow heat exchanger
  • Adsorption motor in 50/50 configuration (82% bonded silica gel)
  • Cu/Al internal evaporator
  • Cu/Al condenser for waste heat removal
  • Cu/Al condenser for waste heat recovery
  • EC-radial fan for waste heat removal
  • Expansion valve
  • G4 filter section
  • Three-way valve with modular control in pressure pipe
  • Process air fan with IEC3 motor

The following system specifications can be determined as needed.

  • Dehumidification capacity (litres/hour)
  • Outside air maximum
    • Temperature (°C) Absolute humidity (g.kg-1)
    • Filterclass process air
  • Available external static pressure process air (Pa)
  • Housing dimensions (mm)
  • Electrical connection (V/ph/A)
  • Outflow dehumidifier
    • Flow rate (m3/h)
    • Available external pressure (Pa)
    • Temperature (°C)
    • Absolute moisture content (g.kg-1)
    • Blow off residual heat (m3/h)
Contact our experts for advice or information

    Request advice

    Mollier diagram

    The Mollier diagram, also known as the h-x diagram, is a visual tool used to represent the thermodynamic properties of moist air. The diagram was developed by Richard Mollier in 1923 and is often used in industry for applications such as air handling, refrigeration and heating systems. Our experts at Reinders Industrial can help advise you on the Mollier Diagram.

    Download Mollier Diagram
